AF66T is an automotive grade Wi-Fi 6 and Bluetooth 5.2 module with high performance, supporting 2 × 2 + 2 × 2 MU-MIMO. It is designed to be used together with Quectel automotive modules AG52xR, AG55xQ and AG57xQ family modules to establish WLAN and Bluetooth connections.
With a compact and unified form factor of 23.0 mm × 23.0 mm × 3.0 mm, AF66T is an ideal Wi-Fi/Bluetooth solution for size-sensitive applications, and helps customers reduce product size and optimize application design cost. The surface-mount technology enhances its durability and robustness, and the LGA package makes sure the module can be easily embedded into size-constrained applications and provide reliable connectivity with these applications. The advanced package allows for large-scale automated manufacturing which has strict requirements on cost and efficiency.
Designed with a reliable PCIe 2.0 interface to provide WLAN capability, AF66T achieves low-power and high-speed data transmission. Coupled with its compact size and wide temperature range, AF66T can meet Wi-Fi/Bluetooth + LTE-A/5G application design requirements in automotive industry.
Key Benefits
- Automotive grade Wi-Fi & Bluetooth module supporting 2.4 GHz and 5 GHz Wi-Fi and Bluetooth 5.2
- Support DBS and dual MAC
- Support PCIe 2.0 and UART interfaces which provide higher data transmission rate and lower power consumption
- Good co-existence with Quectel LTE-A/5G module
- Ideal for automotive market applications with IATF 16949: 2016 requirement, compliant with automotive quality processes such as APQP and PPAP
- Wide operating temperature range (-40°C to +85°C) and superior anti-electromagnetic interference capability meet the demanding requirements for automotive devices
- Fast time-to-market: simple design minimizes design-in time and development efforts
