AF31G is an automotive grade Wi-Fi 5 and Bluetooth 5.0 module with high performance. It is designed to be used together with Quectel automotive AG52xR series module to establish WLAN and Bluetooth connections, supporting 2 × 2 MIMO.
With a compact and unified form factor of 23.0 mm × 23.0 mm × 3.0 mm, AF31G is an ideal Wi-Fi & Bluetooth solution for size-sensitive applications, and helps customers reduce product size and optimize application design cost. The surface-mount technology enhances its durability and robustness, and the LGA package makes sure the module can be easily embedded into size-constrained applications and provide reliable connectivity with these applications. The advanced package allows for large-scale automated manufacturing which has strict requirements on cost and efficiency.
Designed with a reliable PCIe 2.0 (or SDIO 3.0) interface to provide WLAN capability, AF31G achieves low-power and high-speed data transmission. Coupled with its compact size and wide temperature range, AF31G enables the module to meet Wi-Fi/Bluetooth + LTE-A application design requirements in automotive industry.
Key Benefits
- Automotive grade Wi-Fi & Bluetooth module supporting 2.4 GHz and 5 GHz Wi-Fi and Bluetooth 5.0
- Support 2 × 2 MIMO
- Support PCIe 2.0 (or SDIO 3.0), PCM and UART interfaces which provide higher data transmission rate and lower power consumption
- Good co-existence with Quectel LTE-A module
Ideal for automotive market applications with IATF 16949: 2016 requirement, compliant with automotive quality processes such as APQP and PPAP - Wide operating temperature range meets the demanding requirements for automotive devices
- Fast time-to-market: simple design minimizes design-in time and development efforts
